EICHER Skyline 2075 H AC

The all new Skyline is completely revamped with distinctively premium looks, 2350 mm wide bus body, silent & grease free parabolic suspension and radial tubeless tyres. Skyline school buses offer the right blend of safety, comfort and performance to ensure that every journey of the students is safe and comfortable. BSVI skyline is driven by state-of-the-art E474 engine which provides powerful performance. Its superior fuel efficiency coupled with lower maintenance cost leads to high profitability.

Seating Capacity43
EngineE474
Power140HP
Torque400Nm
Fuel TypeDiesel
  • Specifications
  • Benefits
  • Technology
SPECIFICATIONS 2075 H AC
Seating Capacity 41+1+D (3X2)
Wheelbase (mm) 4320
Overall Length (mm) 8112
Overall Width (mm) 2350
Overall Height (mm) 2975
Min Ground Clearance (mm) 187
Front Overhang (mm) 1200
Rear Overhang (mm) 2592
Turning Circle Diameter (m) 16
Engine Make  E474
Displacement (cc) 2960
Power 140 hp (105kW) @ 3200 rpm
Torque  400Nm @ 1200-2500 rpm
Clutch (mm) 310
Transmission Make ET35S5
Transmission Type  synchromesh (5 Speed,1 Rev)
GVW (Tonnes) 8.4
Chassis Type   Domex 650
Chassis C frame dimensions (mm) 200x65x5
Fuel Tank Capacity (l) 100
Brakes  Dual Circuit 'S' Cam Full Air brakes
Tyres 235/75 R17.5- 14PR  (Radial Tubeless )
Suspension Front Parabolic with Anti-Roll Bar
Suspension Rear Parabolic
Steering  Power Steering
Battery  12V 130Ah
Alternator  110A x 2
Flooring  Vinyl
DEF Tank Capacity (l) 19

Next Gen Features

Eicher Live lets you track your vehicle and glance at vital performance parameters at the touch of a button. Fuel coaching and Mbooster+ encourage and enable the driver to operate

Comfort & Convenience

Skyline school buses offer wide and comfortable seats, silent parabolic suspensions and tubeless tyres for superior ride-comfort. Under-seat bag trays, bottle hangers and hatracks

Reliable and Strong

Eicher’s all new E474 engine delivers high power and torque while remaining true to the promise of best in class fuel efficiency. The Skyline range comes with the highly reliabl

M-Booster+

MBooster+ allows the driver to drive in different modes of load and gradient to achieve best-in-class fuel efficiency

Cruise Control

Cruise control maintains speed/rpm without pressing ABC control pedals which leads to fatigue-free driving and higher fuel economy

Eicher Live

An innovative and intelligent telematics system, Eicher Live facilitates in keeping a track of fuel consumption, maintenance needs, and monitoring the movement of buses.
