| PARAMETERS |
Value |
| GVW |
25000 kg |
| Engine Type |
E683-TCI-113-(N), 6 Cylinder |
| Max Power |
154 hp @2600 rpm |
| Max Torque |
569 Nm @ 1440 rpm |
| Clutch Type |
Single dry plate diaphragm type hydraulic actuated |
| Clutch Diameter |
352 mm |
| Gear Box |
ET80S6, 6 Forward & 1 Reverse |
| Chassis Type |
C Channel Ladder type with 6 mm thick side member & 5 mm thick Stiffner. Dimension: 285 X 76 X 6 |
| Suspension |
Front: Semi elliptical laminated leaf springs,Hyd. Type double acting shock absorber |
| Rear: Semi elliptical laminated leaf springs with Bell Crank Mechanism |
| Steering |
Power Steering |
| Max Speed |
77 kmph |
| Electrical |
12 V |
| Fuel Tank |
395 litres |
| Tyre |
10.00 x 20 - 16PR Radial tyre |
| Axle |
Front: Heavy duty forged "I" beam reversed elliot type |
| Rear: Heavy duty fully floating banjo type |
| Gradiability(%) |
23% |
| Varient |
Cowl chassis | Cabin chassis | Cabin & FSD | Cabin & HSD |
| Wheelbase |
4900 mm | 5260 mm |
| Turning Circle Diameter |
17.54 m | 18.4 m |
GVW25000 kg
EngineE683-TCI-113-(N), 6 Cylinder
Power154 hp
Torque569 Nm
Transmission ET 80 S6
