EicherPro 6025T
Eicher Pro 6025T is the new generation 25 ton GVW tipper equipped with highly fuel efficient VEDX8, 6 cylinder,7.7 litre CRS engine designed in association with Volvo Group and a Next Gen cabin with state of art features.
GVW25000 kg
EngineVEDX8
Power220 hp
Torque850 Nm
Transmission 9 Speed
Tipper Body Size14/16 cum
| SPECIFICATIONS | Eicher Pro 6025T |
|---|---|
| GVW | 25000 kg |
| Wheelbase | 4000 mm |
| Front overhang | 2085 mm |
| Rear Overhang | 1926 mm |
| TCD | 14.5 m |
| Engine Type | VEDX8 BSIII 7.7 liters |
| Max Power | 220 hp @ 2200 rpm |
| Max Torque | 850 Nm @1100-1700 rpm |
| Clutch Type | Booster assisted pull type |
| Clutch Diameter | 430 mm |
| Gearbox | ZF make, 9 Forward 1 Reverse |
| Rear Axle | Meritor Tandem-Fully floating Banjo |
| Final Drive Ratio | 5.29 |
| Chassis Type | Domex650 ladder type joggle frame, 285 x 76 x 7 mm |
| Suspension | Front: Semi-Elliptical with anti roll bar Rear: Bogie suspension Hydraulic double acting telescopic type at front only |
| Shock Absorbers | Hydraulic Double Acting Telescopic type at front only |
| Steering | Tilt and Telescopic hyadraulic power steering |
| Body Size | 16 Cum Box & 14 Cum Rock |
| Gradiability(%) | 42.50% |
| Max Speed | 79.6 kmph |
| Fuel Tank | 220 litres |
| Electrical | 2 x24 V, 150 Ah |
| Tyre | 11R-22.5 (Tubeless)- 16PR |
Sand
stone
Blue metal
road construction
Best in class torque at wheel
high reliablity and durablity
optimized maintenance cost
Superior uptime
Faster turn around time
High fuel efficiency
