EICHER Pro 5025T

Move ahead in your trucking business with Eicher Pro 5025T having competitive fuel efficiency backed by Volvo group's expertise. Eicher enchanced lifetime support solutions and a contemporary cabin for superior ride comfort to boost driver efficiency.

GVW25000 kg
EngineCummins 5.9
Power180 hp
Torque685 Nm
Transmission ZF 1110TD
Tipper Body Size16 cum
  • Specifications
  • Benefits
  • Technology
  • Applications
Features Pro 5025T
GVW 25000 kg
Max Power 180 Hp@2500 rpm
Max Torque 685 Nm @ 1500 rpm
Clutch Type Coil spring push type
Clutch Diameter 380 mm
Gearbox ZF 1110TD, 8 Forward, 1 Crawler & 1 Reverse
Front Axle Reverse Elliot type I beam
Rear Axle Meritor Axle
Chassis Type Rolled C-channel straight frame, 285x76x6 mm
Suspension Front: Semi elliptical laminated leaf springs w/o Anti roll bar
Rear: Bogie suspension with 11 leaves
Steering Hydraulic Power Steering
Gradiability 43%
Max Speed 78 kmph
Fuel Tank 220 litres
Electrical 24 V
Tyres 10x20-16PR
Wheelbase 5000 mm
Body size & type 16 CuM , Box Type

Tough and robust aggregates

High reliability and durability

Low maintenance cost

Life time support solution

Instrument Cluster with LCD display

ZF 9S gear Box

Cummins 5.9 Engine with 180 HP & 685 Nm torque

Heavy duty Bogie suspension


Road Construction
