EICHER 2090 L Chassis

The all-new 2000 series chassis is designed to deliver best in class operating economics and superior on road performance, coupled with a lower maintenance costs leading to high profitability for its owners. Powered by advanced new E474 engine, Eicher chassis is smartly designed to deliver powerful performance without compromising on fuel efficiency.

GVW9.8 t
EngineE474
Power 105 kW
Torque400 Nm
Fuel TypeDiesel
  • Specifications
  • Benefits
  • Technology

SPECIFICATIONS 2090 L
Wheelbase 5240 mm
Overall Length 9284 mm
Overall Width 1990 mm
Overall Height 2511 mm
Ground Clearance 187 mm
Front Overhang 1024 mm
Rear Overhang 3020 mm
Turning Circle Diameter 19.4 m
Engine Make  E474
Displacement (cc) 2960
Power  105 kW @ 3200rpm
Torque  400Nm @ 1200-2500rpm
Clutch 310 mm
Transmission Make ET35S6 ,ET35S5
Transmission Type  Synchromesh (6SPeed+1Rev) , Synchromesh (5SPeed+1Rev)
GVW 9.8 t
Chassis Type  Domex 650
Chassis dimension  200X75X5 mm
Fuel Tank Capacity 160 litres
Brakes  Dual Circuit 'S' Cam Full Air brakes
Tyres 8.25x16 - 16 PR
Suspension Semi elliptic
Steering  Power steering
Battery  12V, 130Ah
Alternator  110A
DEF Tank Capacity 19 litres

Assured Reliability

The Domex® chassis is designed to deliver more. Light weight and reliable, it offers superior performance, APDA reduces moisture and oil from the air to increasing the life of the pneumatic system.

Fluid Economy

Best-in-class fuel efficiency delivered by Fuel coaching and Mbooster+ that enable the driver to operate in the most fuel efficient manner. Efficient engine coupled with an advance EATS ensures optimized fuel and AdBlue consumption.

Next Gen Features

New Three spoke easy to adjust steering wheel, new instrument cluster with intelligent display for better drive aids, mileage enhancing Cruise control are some of the latest feature in 2000 series.

Long lasting Durability

A complete peace of mind through stronger aggregates Lubricated For Life Propeller shaft and steering, improved suspension and corrosion free HPDE adblue tank is built in the Eicher 2000 chassis series.

Dynamic Fuel Coaching

Fuel coaching personally guides the driver towards the right selection of gear and rpm to help achieve higher fuel economy

M-Booster+

 MBooster+ allows the driver to drive in different modes of load and gradient to achieve best-in-class fuel efficiency

Cruise Control

 Cruise control maintains speed/rpm without pressing ABC control pedals which leads to fatigue-free driving and higher fuel economy

IDIS 2.0

Intelligent Driver Information System 2.0 keeps the driver informed of all the key parameters through an easy to read display and tell-tales.

BSVI E 474 Engine

The new E 474 BSVI engine delivers higher power and torque while remaining true to the promise of best in class fuel efficiency.
