Eicher 2075 H AC Chassis

The all-new 2000 series chassis is designed to deliver best in class operating economics and superior on road performance, coupled with a lower maintenance costs leading to high profitability for its owners. Powered by advanced new E474 engine, Eicher chassis is smartly designed to deliver powerful performance without compromising on fuel efficiency.

  • GVW
    GVW8.2 t
  • Engine
  • Power
    Power 105 kW
  • Torque
    Torque400 Nm
  • Fuel Type
    Fuel TypeDiesel

Wheelbase 4320 mm
Overall Length 7811 mm
Overall Width 1990 mm
Overall Height 2480 mm
Ground Clearance 187 mm
Front Overhang 1024 mm
Rear Overhang 2467 mm
Turning Circle Diameter 16 m
Engine Make  E474
Displacement (cc) 2960
Power  105 kW @ 3200 Rpm
Torque  400Nm @ 1200-2500 Rpm
Clutch 310 mm
Transmission Make ET35S5
Transmission Type  Synchromesh ( 5 SPeed+1Rev)
GVW 8.2 t
Chassis Type  Domex 650
Chassis dimension  200X75X5 mm
Fuel Tank Capacity 100 litres
Brakes  Dual Circuit 'S' Cam Full Air brakes
Tyres 7.50 X 16 -16 PR
Suspension Semi elliptic
Steering  Power steering
Battery  12V, 130Ah
Alternator  2 x 110A
DEF Tank Capacity 19 litres


 MBooster+ allows the driver to drive in different modes of load and gradient to achieve best-in-class fuel efficiency

Cruise Control

 Cruise control maintains speed/rpm without pressing ABC control pedals which leads to fatigue-free driving and higher fuel economy

IDIS 2.0

Intelligent Driver Information System 2.0 keeps the driver informed of all the key parameters through an easy to read display and tell-tales.

BSVI E 474 Engine

The new E 474 BSVI engine delivers higher power and torque while remaining true to the promise of best in class fuel efficiency.
