Pro 5016T

Driven by a 127 kw engine, Eicher Pro 5016T is a highly reliable 16 Ton GVW tipper with tough and robust aggregates, which delivers best-in-class fuel efficiency. The truck comes with advanced features, including, engine protection system, driver information systems, fuel coaching, cruise control and is supported by Lifetime Support Solutions. Available in Cabin, Cowl and Fully Built options of 8.5 Cum and 10 Cum with both underbody and front end tipping, Eicher Pro 5016T is designed to deliver profitability by optimizing the ownership cost.

Tough & robust
Lifetime Support Solutions
IDIS with Fuel coaching and cruise control
E-694 i3 EGR Engine with Volvo Group's EMS 3.0
Best-in-class fuel efficiency
E-694 Engine with Volvo group's EMS 3.0
IDIS with Fuel coaching and cruise control
STONES
SAND
LAND FILLING
IRON ORE
COAL
BLUE METAL

SPECIFICATIONS

Features Eicher Pro 5016T BSIV
GVW(Kg) 16200
Engine Type E694 5.7 - liter CRS with EGR Technology
Max. Power 143 kw (192 HP) @ 2400 RPM
Max Torque 715 Nm @ 1200-1800 RPM
Clutch Type Hydraulically actuated push type with clutch booster
Clutch Diameter (Mm) 395 mm
Gearbox ET90S6, 6 Forward & 1 Reverse
Front Axle Reverse Elliot I-beam
Rear Axle Heavy Duty Fully Floating
Chassis Type 'C' channel ladder type frame, 285x76x6 mm
Brakes Service Brake: Dual circuit full air 'S' cam
Parking Brake: Full air hand operated on rear wheels
Suspension Front: Semi Elliptic laminated leaf spring
Rear: Semi Elliptic laminated leaf spring
Steering Tilt & telescopic hydraulic power steering
Wheelbase (mm) 3485
Gradeability (%) 43%
Max. Speed (kmph) 82
Fuel Tank 220L
Electricals 24V
Tyres 10x20 - 16PR
Variants 10cum FBT, 8.5cum FBT, CBC
