EICHER Pro 5016

Eicher Pro 5016 is a highly reliable 16 ton GVW truck, which offers the best- in-class fuel efficiency with innovative technology. The truck comes with a 5.7 litre 4 valve 6 cylinder CRS E694 engine with i3 EGR technology and a 6 speed gearbox with overdrive for faster turnaround. With availability in 4 different wheelbases and load spans, Eicher Pro 5016 is suited to deliver performance across various applications.

GVW16200 kg
EngineE694 5.7 - liter CRS with EGR Technology
Power192 hp
Torque715 Nm
Transmission ET90S6
Cargo body length2590.8 to 3048 mm
  • Specifications
  • Benefits
  • Technology
  • Applications
Features Eicher Pro 5016T BSIV
GVW 16200 kg
Engine Type E694 5.7 - liter CRS with EGR Technology
Max. Power 143 kw (192 HP) @ 2400 RPM
Max Torque 715 Nm @ 1200-1800 RPM
Clutch Type Hydraulically actuated push type with clutch booster
Clutch Diameter 395 mm
Gearbox ET90S6, 6 Forward & 1 Reverse
Front Axle Reverse Elliot I-beam
Rear Axle Heavy Duty Fully Floating
Chassis Type 'C' channel ladder type frame, 285x76x6 mm
Brakes Service Brake: Dual circuit full air 'S' cam
Parking Brake: Full air hand operated on rear wheels
Suspension Front: Semi Elliptic laminated leaf spring
Rear: Semi Elliptic laminated leaf spring
Steering Tilt & telescopic hydraulic power steering
Wheelbase 3485 mm
Gradeability (%) 43%
Max. Speed (kmph) 82
Fuel Tank 220 litres
Electricals 24V
Tyres 10x20 - 16PR
Variants 10cum FBT, 8.5cum FBT, CBC

Low maintainence cost

tough and robust aggregates

high reliablity and durablity

life time support solution

Intelligent driver information system

fuel coaching

Cruise Control

E694 engine with Volvo group\'s EMS 3.0

lpg cylinder

food grains

courier and parcel


white goods


market load
