EicherSkyline 20.15
Eicher Skyline 20 . 15 is powered by the high performance 6 cylinder 4 valve E694 VEDX 5 engine with CRS technology which delivers best-in-class fuel efficiency and provides non-stop performance.
Seating Capacity65+D (3x2)
EngineE694 VEDX 5
Power180 hp
Torque670 Nm
Transmission 6 speed
Fuel TypeDiesel
- Specification
- Applications
- Benefits
| SPECIFICATIONS | 20.15 LHD N WB HVAC SD | 20.15 LHD R WB HVAC SD |
|---|---|---|
| Engine | VEDX 5 E5 | VEDX 5 E5 |
| Max. Power | 210 HP @ 2200RPM | 210 HP @ 2200RPM |
| Max. Torque | 825 Nm @ 1200 ~1600 RPM | 825 Nm @ 1200 ~1600 RPM |
| Air intake | Dry Type air cleaner | Dry Type air cleaner |
| Cooling System | Radiator with intercooler suitable for Middle east application | Radiator with intercooler suitable for Middle east application |
| Manual operated type Gear Box | ET90S6 (7.40-0.80) ,Manual | ET90S6 (7.40-0.80) ,Manual |
| Clutch | 395 Dia. With Clutch Booster | 395 Dia. With Clutch Booster |
| Prop Shaft | 2040 DANA | 2040 DANA |
| Gear Shift Linkage | Single Rod GSL | Single Rod GSL |
| Rear Axle | RAR 4.8 (440 DH) | RAR 4.8 (440 DH) |
| Vehicle Weight (Kg) Built-up | Built Up Bus-Calculated | Built Up Bus-Calculated |
| FAW (Laden) | 6265 | 6565 |
| RAW (Laden) | 10435 | 10735 |
| GVW (with (90% fuel) | 16700 | 17300 |
| FAW (Un-Laden) | 5860 | 5750 |
| RAW (Un-Laden) | 5890 | 6225 |
| GVW (Un-Laden) | 11750 | 11975 |
| Wheel Base | 5840mm | 6200 mm |
| Front Overhang | 2260mm (CWC) 2360mm (BU) | 2260mm (CWC) 2360mm (BU) |
| Rear Overhang | 3415mm (CWC) 3535mm (BU) | 3815mm (CWC) 3905mm (BU) |
| Front Wheel Track | 2096mm | 2096 mm |
| Rear Wheel Track | 1869 mm | 1869 mm |
| Angle of Approach(Laden) | 10.5° | 10.5° |
| Angle of Departure (Laden) | 10° | 8.5° |
| Ramp over angle (Laden) | 13.5° | 12.5° |
| Length | 11515mm (CWC) 11735mm (BU) | 12275mm (CWC) 12465mm (BU) |
| Width | 2550mm (CWC) 2600mm (BU) | 2550mm (CWC) 2600mm (BU) |
| Height (Un-Laden) | 2495mm (CWC) 3615mm (BU) | 2495mm (CWC) 3615mm (BU) |
| Frame C section dim(in mm) -DepthXWthXThk | Straight Frame-230X76X6 | Straight Frame-230X76X6 |
| Frame Width | 900mm | 900mm |
| Fuel Tank | 425 Ltr.(Plastic) | 425 Ltr.(Plastic) |
| Adblue | 33L | 33L |
| Steering | Power Steering, Column tilt and Telescopic with column cover | Power Steering, Column tilt and Telescopic with column cover |
| Steering Wheel Dia | 460+2mm | 460+2mm |
| Ratio | 23.6:1 | 23.6:1 |
| Max. Speed (KMPH) | 107 Km/Hr | 107 Km/Hr |
| Gradebility(@ Gear1) | 27% | 26% |
| Min Turning Circle Dia. | 22.7m | 24m |
| Suspension Front | Front Waveller Suspension (w/o spacer) | Front Waveller Suspension (w/o spacer) |
| Suspension Rear | Rear Waveller Suspension (w/o spacer) | Rear Waveller Suspension (w/o spacer) |
| Shock Absorber | Hydraulic double acting telescope shock absorber at front and rear | Hydraulic double acting telescope shock absorber at front and rear |
| Cowl | Faceless cowl with PVC knitted with 3-way mechanical suspended driver seat with 3 point seat belt | Faceless cowl with PVC knitted with 3-way mechanical suspended driver seat with 3 point seat belt |
| Brakes | Dual circuit S-CAM brake circuit 10 Bolt & 10 BAR system | Dual circuit S-CAM brake circuit 10 Bolt & 10 BAR system |
| Service Brake | Brake Size Front- 410 mm X200 mm | Brake Size Front- 410 mm X200 mm |
| Brake Size Rear - 410 mm X220 mm | Brake Size Rear - 410 mm X220 mm | |
| Parking Brake | Spring brake acting at rear wheel | Spring brake acting at rear wheel |
| Pneumatic controlled, Spring Brake | Pneumatic controlled, Spring Brake | |
| ABS system | Yes (ABS:- 4S-3M) | Yes (ABS:- 4S-3M) |
| Electrical Battery | 2 X 12 Volt, 150 AH | 2 X 12 Volt, 150 AH |
| Alternator | 90amp X 1, 24V | 90amp X 1, 24V |
| System | 24Volt | 24Volt |
| Front Axle | I - Beam Reverse Elliot type | I - Beam Reverse Elliot type |
| Wheels and Tyres Front, Spare and Rear | 11R22.5 - M rated(Tubeless) | 11R22.5 - M rated(Tubeless) |
| Wheel Rim | 8.25X22.5 (10 Bolts) | 8.25X22.5 (10 Bolts) |
| Seating capacity - BU | 65 Seater single door 3x2 | 70 Seater single door 3x2 |
| Badging | 20.15 | 20.15 |
| AC | JTAC (Auxilliary) | JTAC (Auxilliary) |
