PARAMETERS |
Value |
ENGINE |
Type |
E694 EGR BSIII |
Max. Power |
180 hp @ 2400 rpm |
Max. Torque |
670 Nm @ 1200-1400 rpm |
PERFORMANCE |
Gradeability (running) |
25% |
Min. TCD |
22.5 m |
CLUTCH |
Type |
395 mm with clutch diameter clutch booster |
GEARBOX |
Model |
ET70S6 |
Type |
6 Forward (with overdrive) & 1 Reverse Gear,
Single Rod GSL |
AXLE |
Front |
I - Beam Reverse Elliot type |
Rear (FDR) |
5.286 |
WHEEL RIM & TYRE |
Tyre Size |
11R22.5 - 16 PR Tubeless Radial |
SUSPENSION |
Front and Rear |
Weveller suspension |
Shock Absorber |
Hydraulic double acting telescope shock absorber at front and rear |
STEERING |
Type |
Power Steering, Tilt & Telescopic type |
ELECTRICAL SYSTEM |
System Voltage |
24 Volt |
Battery |
24V, 150Ah X2 |
Alternator |
24V, 100 amp |
Battery Cut off Switch |
Electronic type |
FUEL TANK |
Capacity |
395 litres |
BRAKES |
Type |
Air brake with ABS |
Service Brakes |
Dual circuit, Full Air S-cam brake |
Exhaust Brakes |
Available |
Parking Brake/ Location |
Spring Brakes Acting on Rear Wheels |
SEATING CAPACITY |
3x2 configuration |
58+D (Skyline 20.15DD) |
DIMENSIONS |
Wheelbase |
5840 mm |
Rear Overhang |
3520 mm |
Front Overhang |
2240 mm |
Overall Length |
11600 mm |
Internal Height |
1925 mm |
Overall Width |
2590 mm |
GVW |
16200 kg |
AC |
Capacity |
Eberspacher - 36.6 KW |
