EICHER Skyline 20.15

Eicher Skyline 20 . 15 is powered by the high performance 6 cylinder 4 valve E694 EIII engine with CRS technology which delivers best-in-class fuel efficiency and provides non-stop performance.

Seating Capacity 65+D (3x2)
EngineE694 EGR BSIII
Power180 HP
Torque670 Nm
Transmission 6 speed
Fuel TypeDiesel
  • Specifications
  • Benefits
  • Technology
  • Applications
PARAMETERS Value
ENGINE Type E694 EGR BSIII
Max. Power 180 hp @ 2400 rpm
Max. Torque 670 Nm @ 1200-1400 rpm
PERFORMANCE Gradeability (running) 25%
Min. TCD (m) 22.5 m
CLUTCH Type 395 mm with clutch diameter clutch booster
GEARBOX Model ET70S6
Type 6 Forward (with overdrive) & 1 Reverse Gear, Single Rod GSL
AXLE Front I - Beam Reverse Elliot type
Rear (FDR) 5.286
WHEEL RIM & TYRE Tyre Size 11R22.5 - 16 PR Tubeless Radial
SUSPENSION Front and Rear Weveller suspension
Shock Absorber Hydraulic double acting telescope shock absorber at front and rear
STEERING Type Power Steering, Tilt & Telescopic type
ELECTRICAL SYSTEM System Voltage 24 Volt
Battery 24V, 150Ah X2
Alternator 24V, 100 amp
Battery Cut off Switch Electronic type
FUEL TANK Capacity 395 litres
BRAKES Type Air brake with ABS
Service Brakes Dual circuit, Full Air S-cam brake
Exhaust Brakes Available
Parking Brake/ Location Spring Brakes Acting on Rear Wheels
SEATING CAPACITY 3x2 configuration 65+D (3x2)
DIMENSIONS Wheelbase (mm) 5840
Rear Overhang (mm) 3520 mm
Front Overhang (mm) 2240 mm
Overall Length (mm) 11600 mm
Internal Height (mm) 1925 mm
Overall Width (mm) 2590
GVW (kg) 16200
AC Capacity Eberspacher - 36.6 KW

Best in class safety

Better driver ergonomics

Superior ride comfort

Superior uptime

Eicher E694 Engine

Intelligent driver information system
