Eicher Pro 6031 is the new generation 31 ton GVW truck equipped with highly fuel efficient 4 cylinder 4 valve engine built on a global platform and a new generation cabin with host of safety and comfort features.
Features | Eicher Pro 6031 | |
---|---|---|
GVW | 31000 kg | |
Engine Type | VEDX5 BSIII 7.7 litres | |
Max Power | 210 hp @ 2200 rpm | |
Max Torque | 825 Nm @1200-1600 rpm | |
Clutch Type | Hydraulic actuated push type Booster assisted | |
Gearbox | ET90S6, 6 forward & 1 reverse | |
Front Axle | Twin steer axle- Reverse Elliot "I" Beam | |
Rear Axle | Heavy duty fully floating | |
Chassis Type | Joggle frame, 285 x 76 x 7 mm | |
Suspension | Front: Semi-Elliptical laminated keaf springs with hydaulic type double acting telescopic shock absorber with ARB Rear: Semi-Elliptical laminated leaf spring with Bell crank mechanism | |
Steering | Tilt and Telescopic hyadraulic power steering | |
Fuel Tank | 380 litres | |
Turning Circle Diameter | 14.5 m | |
Electrical | 24 V | |
Tyre | 10 x 20 - 16PR , Radial tyres | |
Varient | CBC, FSD, HSD | |
Floor | Steel/ Wooden | |
Wheel Base | 6150 | 6150 |
Load Body Span | 7333 mm | 7946 mm |
High Side deck height (Internal) | 1902 / 1890 mm | 1902 / 1890 mm |
Fixed Side Deck Height (Internal) | 905 /894 mm | 905 /894 mm |
Width (Internal) | 2343 mm | 2343 mm |
